Delta Electronics Manufacturing Corp. is a leading global provider of innovative RF, microwave and millimeter wave interconnect solutions. They are proud to deliver a world-class customer experience – by focusing on four key areas: Purpose, Process, People, and Products/Solutions. The Services include: – Application engineering – Design consultation and collaboration u 2D and 3D modeling – ANSYS® HFSS models – Precision CNC Turning and Milling – Heat Treating – Electroplating, passivation, pre-tinning u Cable assemblies, transmission lines and related assemblies – Integrated connectorized housings
New from Delta – Color Code Adapters:
In Testing, Time is Money
High frequency adapter interfaces can be difficult to differentiate and many test engineers spend time having to inspect the contacts and dielectrics closely before being able to tell which ones are which. Delta’s Color Coded Adapters omit all the scrutiny and guess work from the process. Testing engineers and the entire testing team know when they pick up a yellow adapter that it’s a 2.92mm adapter and can get to work.
Color Coding Makes Training Easier
Many testing teams are comprised of lead Test Engineers and then a team of quality support employees that report to the engineers. Color Coding makes it easier for non-engineers to do their jobs more efficiently and make less mistakes.
Organization Makes Everyone’s Job Easier
Test engineers and engineers in general have reputations of liking their spaces organized. A place for everything and everything in it’s place resonates with testing teams. Color coding makes putting the correct adapters where they belong easier.
Mis-mating and damage happens easily
Because of how small the interfaces are, adapters at higher frequency often get mis-mated with the wrong connectors, damaging them beyond repair. Threads get stripped, they become stuck together or contacts and insulators get dislodged with force. Color coding a is sure way to know you’re connecting the correct interfaces.
Other Product series
Originally designed to satisfy the exacting demands of the aerospace industry, our panels are now specified for a wide variety of other applications and environments where operational integrity and clarity of presentation are essential requirements.
Delta Electronics is a leading global provider of innovative RF, microwave and millimeter wave interconnect solutions. They are proud to deliver a world-class customer experience. Below you will find Delta’s extensive catalog of over 330 pages.
Click to open / download the pdf file: Delta RF & Microwave | General Catalog
MIL-PRF-39012 QPL cable connectors are divided into categories which the characteristics of their cable assembly method, and in some cases the actual assembly method.
Category A: Field-serviceable, with no special tools required for assembly. Our Category A connectors in series BNC, N, and TNC are standard military-clamp types; Category A connectors in SMA series are solder type.
Category B: Special tools may be required for assembly. Our Category B connectors in N series are crimp types which use standard, commercially-available crimp tools.
Category C: Crimp-type connectors which can be assembled with tools and die sizes.
Category D: Crimp-type connectors which can be assembled with tools and die sizes, and also have sizes for crimp sleeves, contacts, and other parts. Category D connectors have crimpable center contacts.
Click to open / download the pdf file: Delta Mil-Spec Catalog
Fidelity+ provides a connection system with its focus on the consumer experience. Our IEM product design innovations have been created to support the rigors of the user and the environment. “Flex with Integrity” into tomorrow.
With Delta’s performance enhanced custom IEM designs, innovators will enjoy reliable engineered connection solutions that contribute to signal clarity, with repeatability.
Click to open / download the pdf file: Delta Fidelity Catalog
Delta Electronics Manufacturing Corp. introduces 4 position (VITA 67.1) and 8 position (VITA 67.2) RF connector housings designed for 3U and 6U formats within the OpenVPX ™ architecture. Ideal for blind mating daughtercards to motherboards, the SMPM RF contacts provide +/- .010” radial misalignment tolerance and excellent return loss up to 40 GHz.
Precision machined from either stainless steel or aluminum, the 4 and 8 position housings are available with pre-loaded SMPM adapters or a cost effective, direct snap-in, cable mount SMPM contact. The right angle daughtercard solutions are offered with the direct snap-in SMPM contacts designed for both .047” and .086” flexible semi-rigid cable.
Click to open / download the pdf file: Delta VITA 67 | 4 & 8 Position Connector Housings catalog
Click to open / download the pdf file: Delta Gang Mounts catalog
When Real Estate is an issue, Gang Mounts are the ultimate space savers. It could be a space concern on your PCB or backplane, and or, the need to have or deal with mis-alignment, Delta’s Design Solutions are the answer! Multiple RF/Microwave & Millimeter Wave interconnections available in restricted package spacing are now achievable.
Click to open / download the pdf file: Delta MHF / U.FL | Miniature Coaxial Interconnect System catalog
Delta SSMC connectors are microminiature, 50Ω impedance connectors with 6-40 threaded coupling. SSMC connectors are ideal for use in limited-space applications that require the rugged design of a threaded coupling interface.
They are best suited for use with semi-rigid cables or miniature cables in demanding applications up to 12.4 GHz. Our extensive line of receptacles contains a variety of mounting urations and contact / insulator terminations perfect for any packaging requirements.
Our adapters are available in both in-series and between series. We also o an adapter with a slide-on version of the SSMC interface that is ideal for testing components; reducing wear and tear on mounted connectors and saving time on mating and unmating of test cables.
Click to open / download the pdf file: Delta SSMC | Microminiature, Screw-on-mating High Performance Interconnects catalog
Delta’s 4.1/9.5 Mini DIN series of coaxial connectors were developed to meet the growing demands of today’s high performance mobile
communications systems.
The 4.1/9.5 has an operational frequency range of DC-14 GHz, offers excellent VSWR performance and Low Passive Intermodulation (Low PIM) < -165 dBc. This makes it ideally suited for use in cellular base stations, distributed antenna systems (DAS) and small cell applications. Click to open / download the pdf file: Delta 4.1 / 9.5 Min DIN Low PIM Connectors
heir overall profile allows for system designers to fit these interconnects in to tighter packaging than the majority of micro-minature RF connectors. Both the SMP and SMPM come in a variety of configurations, each with specific features for whatever engineering challenge a designer is facing.
Click to open / download the pdf file: SMP / SMPM / SMP3 High Performance Connectors to 65 GHz
Delta’s threaded SMP-T, SMPM-T and SMP3-T series are ideal for launch vehicle applications. Including hypersonics, satellites, military& commercial aircraft, antenna systems, transportable electronic equipment and any application requiring small size and reliable RF performance.
heir overall profile allows for system designers to fit these interconnects in to tighter packaging than the majority of micro-minature RF connectors. Both the SMP and SMPM come in a variety of configurations, each with specific features for whatever engineering challenge a designer is facing.
Click to open / download the pdf file: SMP-T, SMPM-T and SMP3-T
Their overall profile allows for system designers to fit these interconnects in to tighter packaging than the majority of micro-minature RF connectors. Both the SMP and SMPM come in a variety of configurations, each with specific features for whatever engineering challenge a designer is facing.
Click to open / download the pdf file: Delta SMK 2.92mm | High Performance 40 GHz catalog
Delta introduces two new series of connectors that extend SMA performance beyond the MIL-PRF-39012 upper frequency limit of 18 GHz, while maintaining MIL-STD-348 mating characteristics for backward compatibility with standard SMA connectors when required.
With both 26.5-GHz precision types and 27.0-GHz high-performance types available, you can choose the best price / performance balance for your application, with no need to “overspecify.”
This brochure features configurations to fulfill most standard applications, but any item shown can be customized for
your specific needs.
Click to open / download the pdf file: Delta SMA Extended Frequency | 26.5 GHz / 27.0 GHz catalog
Delta MCX connectors are subminiature, 50Ω impedance connectors with snap-on coupling. They are best suited for use with cables in the range of .070″ to .120″ diameter, such as RG-178 and RG-316/U.
Click to open / download the pdf file: Delta MCX / MMCX catalog
These microminiature switching connectors automatically switch from an internal circuit and an external circuit when mated. They are ideal for use in applications such as portable computers operating in wireless networks, allowing for automatic switching between the internal antenna and a higher gain external antenna.
Their frequency range is DC–3 GHz when switched to internal circuits and DC–8.5 GHz when switched to external circuits. They are compatible with all MC-Card and MMCX plugs.
Click to open / download the pdf file: Delta Switching Connectors | MMCX & MC-Card catalog
Connectors are only as good as their plating, and that’s why we decided this important process needed to be on-site. Having our own plating line, yields high quality, low costs, and reduced lead times. Call us for your electroplating needs.
Click to open / download the pdf file: Delta Electroplating Facility catalog
From avionics to audio, radar to robotics, Delta delivers precision interconnect and innovative solutions to a broad range of industries where reliability, performance, and durability are of paramount importance.
Delta products are found in mission-critical systems across our nation’s armed services, and platforms including homeland security, border control and NATO.
Click to open / download the pdf file: Delta General Capabilities brochure
From avionics to audio, radar to robotics, Delta delivers precision interconnect and innovative solutions to a broad range of industries where reliability, performance, and durability are of paramount importance. Delta products are found in mission-critical systems across our nation’s armed services, and platforms including homeland security, border control and NATO.
Click to open / download the pdf file: Delta General Capabilities brochure
